Main Features:
High Definition
Ultra-fine 1.25mm pixel pitch, providing sharp and detailed images for close viewing (≤1.25m).
Resolution of 256×128 pixels per module (320x160mm), with high-density LED matrix for perfect color integration.
Advanced Technology
SMD1010 LEDs with adjustable brightness (1000-1600nits) and 5000:1 contrast for vivid colors and superior color accuracy.
Refresh rate ≥1920Hz, eliminating flickering effects and ensuring smooth videos.
Modular Design
Standard size of 320x160mm, allowing flexible mounting in horizontal/vertical configurations for custom displays.
Simplified front/rear maintenance and IP65 encapsulation for dust and moisture resistance.
Energy Efficiency
Consumption ≤150W/m² with low thermal dissipation technology, reducing operating costs.
Lifespan >100,000 hours (11+ years of continuous use).
| Technical details | |||
|---|---|---|---|
| Model Number | TL – P1.25 Indoor LED Panel Module | ||
| Brand Name | TELALED Manufacturer | Screen Flatness | <±1mm |
| Place of Origin | Guangdong, China | Mean Time Between Failures (MTBF) | 10,000 Hours |
| Pixel Distance | P1.25 | Useful Life | 100,000 Hours |
| Minimum Viewing Distance | 1.25m | Display Operating Voltage | AC46～54HZ, 220V±15%/110V±15% |
| LED configuration | SMD1010 | Light Attenuation | ＜3% |
| Module Resolution | 160×120 pixels /256×128 pixels | Leakage Current | ＜3mA |
| Module Pixels | 19440 pixels / 32768 pixels | IP Protection Rating | Rear: IP40 / Front: IP50 |
| Module Size | L200mm*H150mm*T17 /L320mm*H160mm*T17 | Temperature and Humidity of the Work Environment | Temp.: -20°C~+60°C / Humidity: 10%~90% RH |
| Cabinet Size | 400mm*300mm /640mm*640mm | Supported Media | Technical data, Photos, CAD models, Video |
| Pixel Configuration | SMD3in1, Full Color R/G/B 1:1:1 | Function | SDK |
| Balanced Shine | 1000cd/m² (indoor) | Control Mode | Synchronization via DVI with control PC |
| Drive Method | 1/32 scan 1/48 scan | Supported Software | Windows XP/W7/Vista |
| Update Rate | ≥1920 Hz | Control System | DVI card + full color controller + optical fiber (optional) |
| Change Detection Frequency | 50-60Hz | Main Control System Mark | Novastar, Linsn, Huidu, Colorlight |
| Viewing Angle | H140° V120° | Interface | Standard Ethernet |
| Inactive Light Rate | ≤1% | Transmission Distance | Multimode fiber <500m > |
| Energy Waste | 700*1000 W/M2 | Guarantee | 5 years |
| Average Energy Consumption | 232 W/M2 | Supplier Type | Original Manufacturer/ODM/OEM |
| Gray Level | 16-bit (281 trillion colors) / 65,536 shades per primary color | Delivery time | 25 (or negotiable) |
| Display Color | 16M | Application | Advertising/Interior/Exterior |
| Uninterrupted Working Hours | ≥72 hours | Use | Digital Advertising, Shopping Malls, Welcome Displays, Exhibition Halls, Airports, Churches, Sports, Events, Meetings, Rentals, Stages, Automotive, Retail, Weddings |
| Discrete Blind Spot Rate | <1> | Packaging Details | Reinforced cardboard box + wood |
| Continuous Blind Spot Rate | None | Supply Capacity | 5,000 units/month |
| Blind Spot Rate | <1> | Harbor | Shenzhen |
